I would like to create a circle-like shape, but with various arcs along the circumference. A better way to explain this is just explain an example.

For example, I want to start with a circle that has a radius of 2 inches, have it gradually grow out to 3 inches over "x" radians, stay at 3 inches for "y" radians, and then return to 2 inches over "z" radians. Is this possible to plot in MATLAB? I am not sure how I would go about getting equations for those arcs and putting them together in a piecewise fashion to display continuously. The center of this circle is irrelevant to the problem, so for simplicity I will say the center of the BASE circle (the 2 in circular arc) is the origin. Picture for reference:

arich82
on 6 Mar 2015

Note that 'smoothly' might not mean what you think it means: depending on your relative radii, you might get a change in concavity even with a "smooth" (continuous derivative) change in radius as a function of angle.

See if the below helps:

r1 = 2;

r2 = 3;

x1 = 4*pi/6; % r = r1

x2 = 2*pi/6; % r 'smoothly' increases

x3 = 3*pi/6; % r = r2

x4 = 2*pi - (x1 + x2 + x3); % r 'smoothly' decreases

t_table = cumsum([ 0, x1, x2, x3, x4, x1]); % note extra wrap-around entry to keep pchip smooth

r_table = [r1, r1, r2, r2, r1, r1];

n = 1000;

method = {'linear', 'pchip', 'spline'};

theta = linspace(0, 2*pi, n + 1);

%radius = interp1(t_table, r_table, theta, 'linear');

for k = 1:numel(method)

radius = interp1(t_table, r_table, theta, method{k});

hf{k} = figure('WindowStyle', 'Docked');

ha{k}(1) = subplot(2, 1, 1);

plot(theta, radius);

xlabel('\theta [rad]')

ylabel('r [u]')

axis([0, 2*pi, 0, r2*1.1])

grid('on')

ha{k}(2) = subplot(2, 1, 2);

plot(radius.*cos(theta), radius.*sin(theta));

title(['Cam Shape (', method{k}, ')'])

axis('equal')

grid('on')

axis([-1, 1, -1, 1]*r2*1.1)

end

(I think keeping a convex shape will depend on if your second region of [larger] constant radius lies within the cone/triangle defined by the two tangents at either end of your first region of [smaller] constant radius.)

Giorgos Papakonstantinou
on 6 Mar 2015

If I understood correctly you mean a spiral. Here's one way then:

turns=5;

theta = 0:pi/180:2*pi*turns;

r = 2*ones(size(theta));

r(theta>1 & theta<=4) = linspace(2, 3, sum(theta>1 & theta<=4)); % radius gradually grows from 1<theta<=4 rad

r(theta>4) = 3; % constant radius for 4 rad<theta<=6 rad

r(theta>6) = linspace(3, 20, sum(theta>6)); % radius gradually grows from 6 rad<theta

X=sin(theta).*r;

Y=cos(theta).*r;

plot(X,Y)

axis square

Of course you can adjust the radians as you wish.
